| SELF LOADING MIXER PARAMETER | ||||||||||
| Item No. | 单位 | SH15 | SH20 | SH25 | SH30 | SH35 | SH40 | SH50 | ||
| 搅拌和装载Mixing and Uniloading | 滚筒容量 | Drum Capacity | m³ | 2 | 3.5 | 4 | 5 | 5.55 | 6.5 | 8.3 |
| 滚筒旋转速度 | Drum rotation speed | r\min | 20 | 20 | 20 | 20 | 20 | 20 | 20 | |
| 混凝土产量 | concrete output | m³\drum | 1.5 | 2 | 2.6 | 3 | 3.5 | 4 | 5 | |
| 发动机Engine | 发动机型号 | Engine model | Yunnei490 Turbo | Yunnei 4102 Turbo | Yuchai 4102 Turbo | Yuchai 4105 Turbo | Yuchai 4105 Turbo | Yuchai 4108 Turbo | Weichai 6105 Turbo | |
| 发动机功率 | Engine power | KW | 58 | 76 | 78 | 85 | 85 | 92 | 92 | |
| 整备参数Vehicle Parameters | 车体长*宽*高 | Overall size (L*W*H) | mm | 5350*1800*2920 | 7040*2695*3000 | 7040*2733*3091 | 7600*2872*3374 | 7600*2872*3374 | 7850*2872*3375 | 8778*3050*3640 |
| 整机重量 | Machine weight | kg | 4500 | 6200 | 6500 | 8300 | 8300 | 9000 | 10500 | |
| 最高车速 | Maximum speed | km\h | 35 | 35 | 35 | 35 | 35 | 35 | 35 | |
| 轴距 | Wheelbase | mm | 2450 | 2570 | 2570 | 2600 | 2600 | 2600 | 2860 | |
| 最大爬坡角度 | Maximum gradeability | ° | 40 | |||||||
| 驱动方式 | Drive | 4×4 | ||||||||
| 离地最小间隙 | Minimum ground clearance | mm | 270 | 280 | 280 | 290 | 290 | 300 | 320 | |
| 变速箱Gearbox | 变速箱 | Gearbox model | JBJ-278 | JBJ-278 | JBJ-278 | JBJ-320 | JBJ-320 | JBJ-320 | JBJ-428 | |
| 档位 | Gearshift | forward 4; back 4 | forward 4; back 4 | forward 4; back 4 | forward 4; back 4 | forward 4; back 4 | forward 4; back 4 | forward 4; back 4 | ||
| 维护加注量Sevice Refill Capacites | 发动机油容积 | Engine oil capacity | L | 12-13 | 13 | 13 | 13 | 13 | 22 | 22 |
| 液压油箱容积 | Hydraulic oil capacity | L | 120 | 120 | 120 | 120 | 120 | 150 | 150 | |
| 燃油箱 | Fuel tank | L | 120 | 120 | 120 | 120 | 120 | 150 | 150 | |
| 供水系统参数paremeters of water supply | 工作水箱 | Water tank | L | 500 | 750 | 750 | 750 | 750 | 750 | 800 |
| 供水方式 | Water supply method | 时间继电器 Time Relay | ||||||||
| 液压系统参数Parameters of Hydraulic system | 减速机 | Reduoer | 3F-130K | 5F-300B | ||||||
| 马达 | Motor | BMS-200 | A2FM63 | |||||||
