| 伸缩臂装载机参数/Telescopic boom loader parameters | |||||
| 一 总体尺寸/Overall size | 伍、发动机/Engine | ||||
| 1 | 外形尺寸/Overall dimension（mm) |
8750*2000*2850 |
1 |
型号/Model |
云内4102增压/YUNNEI 4102 turbocharged |
| 2 | 轴距/wheelbase（mm） | 2650 | 2 | 型式/type | 涡轮增压/turbocharging |
| 3 | 轮距/Track width（mm) | 1560 | 3 | 额定功率/Rated power（KW) | 76 |
| 4 | 最小离地间隙/Minimum ground clearance（mm) | 320 | 4 | 额定转速/Rated power（r/min) | 2400 |
| 二、性能参数/Performance parameter | 5 | 气缸数-内径/Number of cylinders – bore diameter | 4-102 | ||
| 1 | 系统压力/System pressure（Mpa) | 16 | 六、传动系统/Transmission system | ||
| 2 | 整机重量/Machine weight（kg) | 6600 | 1 | 变速箱/Gearbox | 动力换挡/Power shift |
| 3 | 最高车速/Maximum speed（Km/h) | 35 | 2 | 档位数/Number of gears | 前2后2/First two and then two |
| 4 | 最大爬坡能力/Maximum climbing capacity ( ° ) | 35 | 3 | 液力变矩器/Hydraulic torque converter | 280分体高低速/280 split high speed |
| 5 | 最小转弯半径/Minimum turning radius（mm) | 5330 | 七、桥/Axle | ||
| 三、装载伸缩臂参数/Telescopic arm parameter | 1 | 型式/Type | 中大轮边/Large rim | ||
| 1 | 最大举升高度/Maximum lifting height（mm) | 9000 | 八、轮胎/Tyre | ||
| 2 | 最大卸载高度/Maximum unloading height（mm) | 6800 | 规格/Specification | 16/70-20 | |
| 3 | 最高卸载距离/Maximum unloading distance（mm) | 2500 | 1 | 行车制动/Service brake | 气顶油钳盘制动/Gas cap oil clamp disc brake |
| 4 | 最近/远卸载距离/Nearest/far unload distance（mm) | 3500/5900 | 2 | 驻车制动/Parking brake | 手刹/handbrake |
| 5 | 最大载荷/Maximum load（kg） | 2500 | 九、其他/other | ||
| 6 | 最远额定载荷/Furthest load(kg) | 800 | 1 | 驱动型式/Driving type | 四轮驱动/Four-wheel drive |
| 7 | 装斗宽度/Bucket width（mm) | 2000 | 2 | 变速型式/Speed change type | 液力变速/Hydraulic speed change |
| 四、转向系统/Steering system | 3 | 操作系统/Operating system | 电磁液压先导操纵/Electromagnetic hydraulic pilot control | ||
| 2 | 型式/Type | 铰接全液压转向/Articulated full hydraulic steering | |||
| 2 | 转向角度/Steering Angle ( ° ) | 30 | |||
| 具体参数变化以实物为准 | |||||
